Radio receiver EFB-CAN

CAN format 2.0A and 2.0B
CAN data rate of up to 1 Mbit/s
Fixed-code protocol (code length 20 to 40 bits)
Compatible with EFS-HS... / EFS-SS... / EFS-xRP / EFS-12MP radio handheld transmitters
Connection: screw terminals or 5-pin M12 connector
Configuration via USB using a computer (Microsoft Windows 7 or later)
Available for the frequency bands 433 MHz (ISM) or 868 MHz (SRD)

Technical specification
Description
Function
Compatible products
Downloads

Frequency	433 MHz \| 868 MHz
Interface	CAN-Bus 2.0A & 2.0B
Outputs	1
Code setting	Configurable
Programming interface	Mini-USB \| Micro-USB
Power supply	12...24 V DC
Protection class	Max. IP66
Dimensions	Dep.¹
Mounting type	Rail TH 35 \| Surface-mounted

The radio receivers of the EFB-CAN series are suitable for all non-safety-critical applications that require wireless operation via a radio handheld transmitter or a stationary radio transmitter, and a CAN bus connection in CAN format 2.0A and 2.0B.
The radio receiver can be configured quickly and easily using free software and by connecting to a computer via the USB interface.
The receivers of the EFB-CAN series are available in numerous versions based on various product features (e.g. enclosure, electrical connection, RF modules, etc.).

Declaration of Conformity-EFB-v1.1-en

An overview of the key features:

Configuration using standard or extended ID
Transmission rate from 125 kbit/s up to 1 Mbit/s
Various protocol output modes selectable (Normal, Continuous, Single, Remote Frame)
Up to 16 codes (1 code per button resp. key combination or input channel) and thus 16 CAN commands with a data length of up to 8 bytes can be defined
Adjustable CAN bus cycle time and signal time
120 Ω terminating resistor activatable via jumper
Adjustment of RF parameters to compatible radio handheld transmitters
